VIP-WECO no-dig pipe repair seals are internally installed mechanical sealing systems used to rehabilitate leaking and damaged pipelines without excavation. Designed for gravity and low-pressure pipelines, VIP-WECO solutions provide long-term sealing for water, wastewater, industrial and utility infrastructure.
Product Range
What are VIP-WECO No-Dig repair solutions?
The VIP-WECO NO-DIG Pipeline Sealing System is an internally installed mechanical sealing system designed to rehabilitate and permanently seal defective pipe joints, annular gaps, cracks, and damaged lining without excavation.
The system is made of a rubber sealing element (made from EPDM, NBR, HNBR or FKM), hydraulically expanded and restrained by stainless steel tension bands, creating a pressure-tight, mechanically sealed interface between the seal and the host pipe. Once installed, the seal resists groundwater ingress, exfiltration, hydrostatic pressure, and differential movement.
VIP-WECO seals are also suitable for gravity and low-pressure pipelines, including sewers, culverts, and drainage infrastructure, and can be installed in live, flowing systems, significantly reducing programme time, environmental impact, and reinstatement costs compared to traditional open-cut repairs.
VIP-WECO sealing materials comply with recognised industry standards including (WRAS) BS 6920 and even according to Drinking Water Inspectorate (DWI) Regulation 31(4)a for contact with potable water. VIP-WECO has been used extensively on several prominent large scale UK potable water network projects.
Water
Drinking Water
Sewage
Gas
Oil
Industrial
Advantages of the VIP-WECO pipe sealing system.
- Reduced supply interruptions due to quick installation
- Unlike Resin repairs, no curing time; the pipe can be put back into immediate service.
- Significant reductions in excavations because depending on pipe diameter, pipe access is only required every 150-400m
- Can be used with almost all pipe materials (concreted, steel, ductile iron, clay, plastic and GRP)
- In addition to round profiles, other non-circular profiles (egg, ellipse, oval) can be sealed
- No specialist machinery required, the system requires basic tools and a hydraulic installation kit which is available to rent or purchase
- The permanent elasticity and flexibility of the sleeves secure a permanent seal of the pipe joints, even in the event of shifts of the pipe axis after rehabilitation
- Can be used in both horizontal and vertical pipe systems
- Design life of 100+ years
